RTI PIKO RYGB & ROGB
High visibility thanks to yellow / orange OPSL

RTI PIKO RYGB & ROGB

High visibility thanks to yellow / orange OPSL

Built with the latest RTI semiconductor laser module technology and – depending on the model – a yellow or orange Coherent Taipan OPSL module! The RTI PIKO RYGB resp. ROGB projectors are compact show laser systems in a robust, dust-proof housing. The high-end show lasers are ideal for highly professional laser show applications of all kinds. The projectors are completely manufactured in Germany and are built with the latest RTI semiconductor laser modules and a yellow resp. orange OPSL module for even better visibility. The RSL modules with their very low divergence and a homogeneous beam shape make the RTI PIKO RYGBs and ROGBs highly professional laser systems. The small beam diameter of only approx. 5.0 mm enables the use of small scanner mirrors with less inertia, which enables high scanning speeds. The standard scanners can be operated with a maximum scan speed of 45 kpps @8° ILDA and a maximum scan angle of 50°. CT-6210 scanners with LAS Turboscan drivers are optionally available, enabling even higher scanning speeds of up to 60kpps at ILDA 8° at a maximum of 60°. The intelligent LaserAnimation Sollinger Mainboard is integrated into the laser projector, which provides the laser operator with a variety of control and setting options (e.g. via the LA.toolbox) or transmission options (such as AVB). Together with the optionally available FB4, ILDA, AVB as well as player operation, among others, are available, ensuring the highest possible flexibility. Thanks to the new LAS mainboard, the latest generation of PIKO projectors can be controlled via our Laser Disable Button – a special safety button to interrupt the laser output via Ethernet. Control signals can be looped through directly via the network switch, which is also integrated. In the RTI PIKO RYGB and ROGB lasers, the standard integrated 525 nm green can be replaced by 10 Watt 532 nm OPSL if required. The powerful RTI PIKO RYGB / ROGB systems are suitable for indoor and outdoor applications, e.g. at concerts, festivals and other big events. Demanding graphic projections and projections over long distances are no problem for these devices thanks to the low divergence.

Equipment

Wavelength 638-639 nm 520-530 nm 445-450 nm 577-590 nm
W R G B Y
PIKO 45 RYGB 45 8.5 15 24 6
PIKO 42 ROGB 42 8 15 22 5
Control Modes

AVB / TSN interface for streaming data via Ethernet, AIFF player function, stand-alone player, ILDA, DMX / ArtNET, control software “LA.toolbox” for PC or Mac included, LAN (software) with FB4 (optional)

Scanner
45kpps ILDA 8°, max. 50°
optional: CT-6210 with LAS Turboscan: 60kpps ILDA 8°, max. 60°
Divergence*
<0,7 mrad
Beam Specs
5 mm
Dimensions
L 49,1 cm x W 27,1 cm x H 29,6 cm
Weight
28 kg
IP Rating
54
Scope of Delivery
Incl. waterproof flightcase, power cable, Interlock, key, manual; incl. LA.toolbox control software
*FWHM average depending on model

Properties

  • 42 – 45 W guaranteed power after optics (depending on model)
  • RTI RSL laser module technology for a very good beam profile in all colors
  • Yellow resp. orange Coherent Taipan OPSL (depending on model)
  • Integrated intelligent LaserAnimation Sollinger Mainboard
  • Control via “LA.toolbox” software (color correction, laser disable); software included in delivery
  • AVB interface for streaming data via Ethernet
  • FB4 integration optional
  • Integrated network switch for looping through the control signal
  • LAS motorized dichroic filters optionally available
  • Replacement of the standard integrated 525 nm green with 10 Watt 532 nm OPSL optionally possible
  • Incl. flightcase and rain cover (IP54)
